1. Reasonable configurations for heavy-duty loading work
2. High power electric motor built to Euro III emission standards
3. Electronic-hydraulic control power shift gearbox offers both automatic and manual transmission. 4 forward gears and 4 reverse gears for maximum comfort in operation.
4. Feedback system warns users against high voltage, overload, and other variations in operating status. This accounts for the excellent digging and loading performance, thereby saving energy and improving efficiency.
5. Loader arm comes with smart vibration damping mechanism for prolonged service life and maximum stability and comfort in operation.
6. Reverse rotation fan comes with intelligent temperature control, saving energy and reducing overall maintenance.
7. Hydraulic brake, coupled with pilot-operated safety valve, ensures safety in travel.
8. FOPS/ROPS driver cabin offers a high viewpoint and comfortable operating space.
|Rated bucket capacity(m3)||6.6|
|Diesel engine||Mercedes OM502LA.E3A -4|
|Transmission case||USA 8421|
|Gear positions||8 in total, including 4 forward and 4 reverse gears|
|Max. traction (KN)||397|
|Max. breakout force(KN)||391|
|Max. dump clearance(mm)||3873|
|Total cycle time (s)||15.4|
