Motor Grader 719H

Features of Motor Grader :
1. Equipped with reliable ShangChai SC11CB195G2B1 engine or genuine Cummins engine
2. Sing-handle electro-hydraulic controlled power-shift T/M, 6 forward & 3 reverse shifts makes operation easy and convenient
3. Hydraulic lock, auto lock/unlock NO-SPIN differential ensures stability and powerful traction
4. Ideal axel load allocation provides excellent stability while cutting hard surface
5. Serviceable, efficient hydraulic system enables every part to be fully used
6. Box-typed frame and advanced T/M enable it to complete heavy-duty work
7. A wide working range is accomplished through flexible blade suspension system and articulated frame

Specifications of Motor Grader :
Model 719H
Length×width×height(mm) 9235×4268×3370
Operating weight(Kg) 15900
Max. traction force(KN) 77.2/80.6
Diesel engine type Cummins engine 6ctaa8.3-c185/ShangChai SC11CB195G2B1
Rated output(KW) 138/143
Transmission case type HangChi WG180
Gear shift position 6 Forward and 3 reverse gears
Min. turning radius(mm) 7400
Blade Dimensions 4268×645×18
Max. lifting height(mm) 450
Max. grading depth(mm) 535
Sound quality construction machinery and construction equipment including wheel loaders, road rollers, motor graders, backhoe loaders, skid steer loaders, pavers, concrete truck mixers, Truck Mounted Crane and other high quality construction machinery, construction equipment and engineering vehicle exist in SINOMACH .
